Compared with the common metal roof machine, the glazed roof panel roll forming machine produces the classic roof panel. We choose 0.3mm to 0.8mm thickness material for glazed roof panel,it is more colorful, lightweight and strength. Meanwhile, the special installation type makes the roof more waterproof and heat preservation.
Why choose our glazed roof panel roll forming machine
1.Our machine is manufactured according to the export standard. It means we will paint the frame and wall panel, then we process the components. The machine will not get rusty.
2. We improve the driving power to 5.5kw, the cutting power to 3kw.
3.We enhance the shaft diameter from 70mm to 80mm. Assuredly our metal roof machine will
produce 0.8mm thickness glazed roof panel for a long time without any deform.
| Main parameter for glazed roof panel roll forming machine | ||
| Main power | 5.5Kw | |
| Structure | Middle plate, 16mm thick | |
| Roller station | 16 stations | |
| Roller material | 45#advanced steel, heat treatment HRC58-62, chrome coating | |
| Shaft material | 45# advanced steel | |
| Shaft diameter | Ф80 | |
| Forming Speed | 8-12m/min (as you need) | |
| Material of blade | Cr12Mov | |
| Tolerance | ±1.0mm | |
| PLC brand | Delta (as you need) | |
| Hydraulic power | 3Kw | |
| Machine size | about 6200*1100*1500 mm L*W*H | |
| Machine weight | 3.2T | |
| Voltage | 380V 50hz 3phase (as you need) | |
| Machine color | as your request | |
